♦ Maximum power of single unit: 2-54kW
♦ Voltage range: 150V, 600V, 1200V
♦ Current range: 4U module up to 600A, master/slave parallel control, power expansion up to 600kW
♦ Multiple operating modes: CC, CV, CR, CP, CC+CV, CV+CR, CR+CC, CP+CC *1
♦ Fast current rise and fall and 30kHz dynamic mode *2
♦ CV loop speed adjustable to match different power supplies
♦ Low voltage and high current loading, internal resistance about 0.7mΩ
♦ 500kHz high speed voltage and current sampling rate
♦ Time measurement, battery discharge test
♦ Short circuit simulation, automatic test function
♦ Soft power on, soft power off to prevent voltage fluctuation during on/off
♦ Timing control list programming, OCP/OPP test
♦ I-monitor
♦ Built-in LAN, USB, RS232, GPIB, CAN, external analog
♦ Highly accurate voltage and current measurement
♦ Support OVP, OCP,OPP, OTP, current oscillation protection, current limit, power limit, fan blocking protection, reverse alarm, etc.
♦ Power failure memory function, memory capacity of 100 groups
♦ Independent control by master unit , easy to maintain and install
*1 IT8900L only supports CC, CV, CR, CP
*2 30 kHz only for 150V G-Series models
