sonoma-352

주파수 대역폭

10 kHz ~ 5 GHz

게인

26 ± 1.5 dB

노이즈 피겨

6 dB (typ)

상승 시간

70 psec (typ)

출력 (P1dB)

+10 dBm

주요특징

sonoma-352

제품사양

sonoma-352

Feature	Specification	Condition
Bandwidth	10 kHz–5 GHz	3 dB
Gain	26 ± 1.5 dB	at 2.5 GHz
	20 V/V	non-inverting, 50 Ω load
Gain Flatness	± 0.6 dB	500 kHz–4 GHz
Noise Figure	6 dB typ.	10 MHz–2.5 GHz
Equivalent Input Noise Voltage	0.9 nV / √Hz	including 0.45 nV / √Hz from a 50 Ω source
Output at 1dB Gain Compression	+10 dBm	±1 V, 10 MHz – 4 GHz
Maximum Input for Linear Operation	approx. ± 50 mV
Harmonic Distortion	– 44 dB	0 dBm out, 300 MHz
Third Order Intercept Point	+ 26 dBm	at 300 MHz
Impedance	50 Ω	a.c. coupled
Input Return Loss	12 dB	10 MHz–5 GHz
Output Return Loss	10 dB	10 MHz–5 GHz
Reverse Isolation	37 dB	10 MHz–5 GHz
Rise Time	70 psec	typical
Group Delay Variation	± 60 psec	45 MHz–5 GHz
Connectors	Type N
Input Damage Level
D.C.	±1V
R.F.	0 dBm
Pulse	±150 mV
Temperature Range
Operating	0 to +55°C
Storage	25 to +75°C
Power Requirements	100, 120, 220, or 240V a.c.
	50-60 Hz, 20 VA
Size	3.6″ x 4.3″ x 7.2″ (H x W x D)
	91 x 109 x 183 mm
Net Weight	3.3 lb / 1.5 kg
